Liquid Level Sensor

Technical data: HBLT-A3

The HBLT-A3 capacitive Liquid Level Sensor measures liquid levels in refrigerant vessels, heat pumps, and other industrial applications. This intelligent sensor comes with a built-in microprocessor and has advanced control capabilities for modulating motor valves, stepper valves, or PWM valves.

Key features

  • Liquid temperature range: Operate across a temperature range of -60°C to 110°C (-76°F to 230°F).
  • Pressure tolerance: Rated for pressures up to 100 bar (1450 psi).
  • Power supply: The sensor operates on a 24 V DC power supply.
  • LED indicators: Provides clear visual indicators for power supply and alarm status.
  • Split design: Simplifies installation and diagnostics; electronic parts can be removed with two screws.
  • Easy configuration: Configuration with a PC using HB Tool software.

Read the case story regarding the HBLT-A3 sensor here.

View the embedded image gallery online at:
https://www.hbproducts.dk/en/products/item/1272-nh3-refrigerant-level-sensor#sigProIda58956d993

Product features

Advanced setting for controlling modulating valve
5m M12 cable included
Easy configuration of the sensor
The HBLT-A3 is a perfect solution under turbulent conditions like marine applications
Split design which makes it possible to make easy installation and diagnostics

Applications

HBLT A3 p receiver

HBLT A3 heat pump01 Web





Specifications

Standard versions

All sensors has an analog output

Sensor with M12 connector

Spec 1



Control versions

Spec 2

  • /C for modulating valve
  • /S for stepper motor
  • /PWM for pulse modulating valve



Drawing

HBLT A3 Komp R1 002Web

 HBLT A3 Komp eksplodedR1 002Web

Power supply
Voltage24 AC/DC + 10%
Plug connectionM12, 5 pins - DIN 0627
Output
Analog output 4-20 mA
Environmental conditions
Ambient temperature-30...+50°C
Refrigerant temperature-60...+110°C
Max. pressure100 bar
Protection classIP65
VibrationsIEC 60068-2-6 (4g)
Mechanical specifications
Thread connections3/4” NPT / BSP
Material - mechanical partsAISI 304 / PTFE
Material - electronic partsNylon 6 (PA)
House typeAngle
Approvals
EMC testEN 61000-2
Indication
LED indicationGreen, yellow, and red

Ordering code

Length / threadValve typeOrdering code with LED
200 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-2-6
300 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-3-6
400 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-4-6
500 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-5-6
600 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-6-6
700 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-7-6
800 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-8-6
900 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-9-6
1000 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-10-6
1100 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-11-6
1200 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-12-6
1300 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-13-6
1400 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-14-6
1500 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-15-6
1700 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-17-6
2000 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-20-6
2500 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-25-6
3000 mm / 3/4" BSPPNo direct valve control mA onlyHBLT-A3-30-6
200 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-2-2
300 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-3-2
400 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-4-2
500 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-5-2
600 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-6-2
700 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-7-2
800 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-8-2
900 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-9-2
1000 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-10-2
1100 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-11-2
1200 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-12-2
1300 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-13-2
1400 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-14-2
1500 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-15-2
1700 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-17-2
2000 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-20-2
2500 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-25-2
3000 mm / 3/4" NPTNo direct valve control mA onlyHBLT-A3-30-2
Electronic part for HBLT-A3No direct valve control mA onlyHBLT-A3-EL
200 mm / 3/4" BSPPModulatingHBSLT/C-A3-2-6
300 mm / 3/4" BSPPModulatingHBSLT/C-A3-3-6
400 mm / 3/4" BSPPModulatingHBSLT/C-A3-4-6
500 mm / 3/4" BSPPModulatingHBSLT/C-A3-5-6
600 mm / 3/4" BSPPModulatingHBSLT/C-A3-6-6
700 mm / 3/4" BSPPModulatingHBSLT/C-A3-7-6
800 mm / 3/4" BSPPModulatingHBSLT/C-A3-8-6
900 mm / 3/4" BSPPModulatingHBSLT/C-A3-9-6
1000 mm / 3/4" BSPPModulatingHBSLT/C-A3-10-6
1100 mm / 3/4" BSPPModulatingHBSLT/C-A3-11-6
1200 mm / 3/4" BSPPModulatingHBSLT/C-A3-12-6
1300 mm / 3/4" BSPPModulatingHBSLT/C-A3-13-6
1400 mm / 3/4" BSPPModulatingHBSLT/C-A3-14-6
1500 mm / 3/4" BSPPModulatingHBSLT/C-A3-15-6
1700 mm / 3/4" BSPPModulatingHBSLT/C-A3-17-6
2000 mm / 3/4" BSPPModulatingHBSLT/C-A3-20-6
2500 mm / 3/4" BSPPModulatingHBSLT/C-A3-25-6
3000 mm / 3/4" BSPPModulatingHBSLT/C-A3-30-6
200 mm / 3/4" NPTModulatingHBSLT/C-A3-2-2
300 mm / 3/4" NPTModulatingHBSLT/C-A3-3-2
400 mm / 3/4" NPTModulatingHBSLT/C-A3-4-2
500 mm / 3/4" NPTModulatingHBSLT/C-A3-5-2
600 mm / 3/4" NPTModulatingHBSLT/C-A3-6-2
700 mm / 3/4" NPTModulatingHBSLT/C-A3-7-2
800 mm / 3/4" NPTModulatingHBSLT/C-A3-8-2
900 mm / 3/4" NPTModulatingHBSLT/C-A3-9-2
1000 mm / 3/4" NPTModulatingHBSLT/C-A3-10-2
1100 mm / 3/4" NPTModulatingHBSLT/C-A3-11-2
1200 mm / 3/4" NPTModulatingHBSLT/C-A3-12-2
1300 mm / 3/4" NPTModulatingHBSLT/C-A3-13-2
1400 mm / 3/4" NPTModulatingHBSLT/C-A3-14-2
1500 mm / 3/4" NPTModulatingHBSLT/C-A3-15-2
1700 mm / 3/4" NPTModulatingHBSLT/C-A3-17-2
2000 mm / 3/4" NPTModulatingHBSLT/C-A3-20-2
2500 mm / 3/4" NPTModulatingHBSLT/C-A3-25-2
3000 mm / 3/4" NPTModulatingHBSLT/C-A3-30-2
Electronic part for HBSLT/C-A3ModulatingHBSLT/C-A3-EL
200 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-2-6
300 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-3-6
400 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-4-6
500 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-5-6
600 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-6-6
700 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-7-6
800 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-8-6
900 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-9-6
1000 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-10-6
1100 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-11-6
1200 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-12-6
1300 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-13-6
1400 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-14-6
1500 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-15-6
1700 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-17-6
2000 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-20-6
2500 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-25-6
3000 mm / 3/4" BSPPStepper MotorHBSLT/S-A3-30-6
200 mm / 3/4" NPTStepper MotorHBSLT/S-A3-2-2
300 mm / 3/4" NPTStepper MotorHBSLT/S-A3-3-2
400 mm / 3/4" NPTStepper MotorHBSLT/S-A3-4-2
500 mm / 3/4" NPTStepper MotorHBSLT/S-A3-5-2
600 mm / 3/4" NPTStepper MotorHBSLT/S-A3-6-2
700 mm / 3/4" NPTStepper MotorHBSLT/S-A3-7-2
800 mm / 3/4" NPTStepper MotorHBSLT/S-A3-8-2
900 mm / 3/4" NPTStepper MotorHBSLT/S-A3-9-2
1000 mm / 3/4" NPTStepper MotorHBSLT/S-A3-10-2
1100 mm / 3/4" NPTStepper MotorHBSLT/S-A3-11-2
1200 mm / 3/4" NPTStepper MotorHBSLT/S-A3-12-2
1300 mm / 3/4" NPTStepper MotorHBSLT/S-A3-13-2
1400 mm / 3/4" NPTStepper MotorHBSLT/S-A3-14-2
1500 mm / 3/4" NPTStepper MotorHBSLT/S-A3-15-2
1700 mm / 3/4" NPTStepper MotorHBSLT/S-A3-17-2
2000 mm / 3/4" NPTStepper MotorHBSLT/S-A3-20-2
2500 mm / 3/4" NPTStepper MotorHBSLT/S-A3-25-2
3000 mm / 3/4" NPTStepper MotorHBSLT/S-A3-30-2
Electronic part for HBSLT/S-A3Stepper MotorHBSLT/S-A3-EL
200 mm / 3/4" BSPPPWMHBSLT/PWM-A3-2-6
300 mm / 3/4" BSPPPWMHBSLT/PWM-A3-3-6
400 mm / 3/4" BSPPPWMHBSLT/PWM-A3-4-6
500 mm / 3/4" BSPPPWMHBSLT/PWM-A3-5-6
600 mm / 3/4" BSPPPWMHBSLT/PWM-A3-6-6
700 mm / 3/4" BSPPPWMHBSLT/PWM-A3-7-6
800 mm / 3/4" BSPPPWMHBSLT/PWM-A3-8-6
900 mm / 3/4" BSPPPWMHBSLT/PWM-A3-9-6
1000 mm / 3/4" BSPPPWMHBSLT/PWM-A3-10-6
1100 mm / 3/4" BSPPPWMHBSLT/PWM-A3-11-6
1200 mm / 3/4" BSPPPWMHBSLT/PWM-A3-12-6
1300 mm / 3/4" BSPPPWMHBSLT/PWM-A3-13-6
1400 mm / 3/4" BSPPPWMHBSLT/PWM-A3-14-6
1500 mm / 3/4" BSPPPWMHBSLT/PWM-A3-15-6
1700 mm / 3/4" BSPPPWMHBSLT/PWM-A3-17-6
2000 mm / 3/4" BSPPPWMHBSLT/PWM-A3-20-6
2500 mm / 3/4" BSPPPWMHBSLT/PWM-A3-25-6
3000 mm / 3/4" BSPPPWMHBSLT/PWM-A3-30-6
200 mm / 3/4" NPTPWMHBSLT/PWM-A3-2-2
300 mm / 3/4" NPTPWMHBSLT/PWM-A3-3-2
400 mm / 3/4" NPTPWMHBSLT/PWM-A3-4-2
500 mm / 3/4" NPTPWMHBSLT/PWM-A3-5-2
600 mm / 3/4" NPTPWMHBSLT/PWM-A3-6-2
700 mm / 3/4" NPTPWMHBSLT/PWM-A3-7-2
800 mm / 3/4" NPTPWMHBSLT/PWM-A3-8-2
900 mm / 3/4" NPTPWMHBSLT/PWM-A3-9-2
1000 mm / 3/4" NPTPWMHBSLT/PWM-A3-10-2
1100 mm / 3/4" NPTPWMHBSLT/PWM-A3-11-2
1200 mm / 3/4" NPTPWMHBSLT/PWM-A3-12-2
1300 mm / 3/4" NPTPWMHBSLT/PWM-A3-13-2
1400 mm / 3/4" NPTPWMHBSLT/PWM-A3-14-2
1500 mm / 3/4" NPTPWMHBSLT/PWM-A3-15-2
1700 mm / 3/4" NPTPWMHBSLT/PWM-A3-17-2
2000 mm / 3/4" NPTPWMHBSLT/PWM-A3-20-2
2500 mm / 3/4" NPTPWMHBSLT/PWM-A3-25-2
3000 mm / 3/4" NPTPWMHBSLT/PWM-A3-30-2
Electronic part for HBSLT/PWM-A3PWMHBSLT/PWM-A3-EL

Downloads

Instruction manual - HBLT-A3

Step Files
