Oil Level Switch

All products

Article	Liquid group	Power supply	IP class	Thread	Output	Fluid Temp.	Contact function	IECEx/ATEX

Article	Liquid group	Power supply	IP class	Thread	Output	Fluid Temp.	Contact function	IECEx/ATEX
HBSO1-PNP/NO-2 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NO 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" NPT	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-PNP/NO-1 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NO 1/2" NPT - w. set screw connection Oil 24V AC/DC IP54 1/2" NPT PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1/2" NPT	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO2-PNP/NO-2 Oil Level Switch - IP54 For PAG & POE oil, PNP/NO 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" NPT	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-SSR-1/NO-2/HT High Temperature Oil Level Switch - IP54 NO - 24 V AC/DC, 0 - 145 C - Solid State 3/4" NPT - PAO & Mineral oil - set screw Oil 24V AC/DC IP54 3/4" NPT Solid State Relay 0 to 145°C (32 to 293°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" NPT	Solid State Relay	0 to 145°C (32 to 293°F)	NO (Normally Open)	No
HBSO2-SSR-1/NO-2/HT High Temperature Oil Level Switch - IP54 NO - 24 V AC/DC, 0 - 145 C - Solid State 3/4" NPT - PAG & POE oil - set screw Oil 24V AC/DC IP54 3/4" NPT Solid State Relay 0 to 145°C (32 to 293°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" NPT	Solid State Relay	0 to 145°C (32 to 293°F)	NO (Normally Open)	No
HBSO1-NPN/NC-2 Oil Level Switch - IP54 For PAO & mineral oil, NPN/NC 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT NPN 0 to 80°C (32 to 176°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	3/4" NPT	NPN	0 to 80°C (32 to 176°F)	NC (Normally Closed)	No
HBSO1-PNP/NC-2 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NC 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT PNP 0 to 80°C (32 to 176°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	3/4" NPT	PNP	0 to 80°C (32 to 176°F)	NC (Normally Closed)	No
HBSO1-PNP/NC-1 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NC 1/2" NPT - w. set screw connection Oil 24V AC/DC IP54 1/2" NPT PNP 0 to 80°C (32 to 176°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	1/2" NPT	PNP	0 to 80°C (32 to 176°F)	NC (Normally Closed)	No
HBSO1-NPN/NO-5 Oil Level Switch - IP54 For PAO & mineral oil, NPN/NO 1/2" BSPP - w. set screw connection Oil 24V AC/DC IP54 1/2" BSPP NPN 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1/2" BSPP	NPN	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-SSR-1/NC-2/HT High Temperature Oil Level Switch - IP54 NC - 24 V AC/DC, 0 - 145 C - Solid State 3/4" NPT - PAO & Mineral oil - set screw Oil 24V AC/DC IP54 3/4" NPT Solid State Relay 0 to 145°C (32 to 293°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	3/4" NPT	Solid State Relay	0 to 145°C (32 to 293°F)	NC (Normally Closed)	No
HBSO1-PNP/NO-5 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NO 1/2" BSPP - w. set screw connection Oil 24V AC/DC IP54 1/2" BSPP PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1/2" BSPP	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-SSR-1/NO-1/HT High Temperature Oil Level Switch - IP54 NO - 24 V AC/DC, 0 - 145 C - Solid State 1/2" NPT - PAO & Mineral oil - set screw Oil 24V AC/DC IP54 1/2" NPT Solid State Relay 0 to 145°C (32 to 293°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1/2" NPT	Solid State Relay	0 to 145°C (32 to 293°F)	NO (Normally Open)	No
HBSO1-NPN/NO-2 Oil Level Switch - IP54 For PAO & mineral oil, NPN/NO 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT NPN 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" NPT	NPN	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-PNP/NC-5 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NC 1/2" BSPP - w. set screw connection Oil 24V AC/DC IP54 1/2" BSPP PNP 0 to 80°C (32 to 176°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	1/2" BSPP	PNP	0 to 80°C (32 to 176°F)	NC (Normally Closed)	No
HBSO1-PNP/NO-7 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NO 1 1/8" UNEF - w. set screw connection Oil 24V AC/DC IP54 1 1/8" UNEF PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1 1/8" UNEF	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-PNP/NO-6 Oil Level Switch - IP54 For PAO & mineral oil, PNP/NO 3/4" BSPP - w. set screw connection Oil 24V AC/DC IP54 3/4" BSPP PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	3/4" BSPP	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-SSR-2/NC-2 Oil Level Switch, High volt. 90..240 VAC NC - For PAO & mineral oil - Solid State 3/4" NPT - w. set screw connection IP54 Oil 90-240V AC IP54 3/4" NPT Solid State Relay 0 to 60°C (32 to 140°F) NC (Normally Closed) No	Oil	90-240V AC	IP54	3/4" NPT	Solid State Relay	0 to 60°C (32 to 140°F)	NC (Normally Closed)	No
HBSO2-PNP/NO-1 Oil Level Switch - IP54 For PAG & POE oil, PNP/NO 1/2" NPT - w. set screw connection Oil 24V AC/DC IP54 1/2" NPT PNP 0 to 80°C (32 to 176°F) NO (Normally Open) No	Oil	24V AC/DC	IP54	1/2" NPT	PNP	0 to 80°C (32 to 176°F)	NO (Normally Open)	No
HBSO1-SSR-2/NO-2 Oil Level Switch, High volt. 90..240 VAC NO - For PAO & mineral oil - Solid State 3/4" NPT - w. set screw connection IP54 Oil 90-240V AC IP54 3/4" NPT Solid State Relay 0 to 60°C (32 to 140°F) NO (Normally Open) No	Oil	90-240V AC	IP54	3/4" NPT	Solid State Relay	0 to 60°C (32 to 140°F)	NO (Normally Open)	No
HBSO1-SSR-1/NC-2 Oil Level Switch - Solid State - IP54 For PAO & Mineral oil - NC 3/4" NPT - w. set screw connection Oil 24V AC/DC IP54 3/4" NPT Solid State Relay 0 to 145°C (32 to 293°F) NC (Normally Closed) No	Oil	24V AC/DC	IP54	3/4" NPT	Solid State Relay	0 to 145°C (32 to 293°F)	NC (Normally Closed)	No

1 2 3 4 5

...

Displaying 1 to 20 of 180
